ASRock

SOM-P104J

ModelSOM-P104JSKUP104J
ProcessorIntel Alder Lake-N SoC
Memory32 GB DDR5-4800
GraphicsIntel UHD Graphics

Specifications 28 normalized

Processor
Processor
Intel Alder Lake-N SoC Processors
SOM-P104J (N97, QC, Max Speed Up to 3.6 GHz, 12W)
*For other CPU SKUs request, please contact regional Sales for availability
Memory & storage
Memory
Technology: Single Channel DDR5 4800 MHz
Capacity: 32 GB
Socket: 1 x 262-pin SO-DIMM
Storage
M.2: 1 x M.2 (Key M, 2242/2280) with PCIe Gen3 x1 or SATA3 and USB 2.0 for SSD
Storage Temp
40° C ~ 85° C
Storage Humidity
5% ~ 90%
Graphics
Graphics
Intel UHD Graphics
Display
Display Outputs
HDMI: HDMI 2.0b
Max resolution up to 4096 x 2160@60 Hz
DisplayPort: Display Port 1.4a, DP++
Max resolution up to 4096x2160@60 Hz
LVDS: Dual channel 24 bit up to 1920 x 1200@60 Hz
(Connector shared with eDP)
eDP: Max resolution up to 1920 x 1080@60 Hz
(Connector shared with LVDS)
MultiDisplay: Triple display
Connectivity
Networking
Controller/ Speed: Realtek RTL8125BG with 10/100/1000/2500 Mbps
Rear I/O Ethernet
1 x 2.5 Gigabit LAN
Internal Connector MIPI Camera Header
1 (Optional)
Expansion M.2
1 x M.2 (Key E, 2230) with PCIe Gen3 x1 and USB 2.0 for Wireless
Expansion MIOe
1 (HDMI or DP, 1 x USB 3.2 Gen2, 1 x USB 2.0, 3 x PCIe x1)
Rear I/O HDMI
1 x HDMI 2.0b
Rear I/O USB
1 x USB 3.2 Gen2 (Type A)
Internal Connector USB
2 x USB 2.0 (1x2.00 pitch header)
Internal Connector COM
COM1, COM3 (RS-232/422/485)
Internal Connector GPIO
4 x GPI, 4 x GPO
Internal Connector LVDS
1 (Connector with LVDS/eDP signal, switch by BIOS)
Camera & audio
Audio
Interface: Realtek ALC897 HD, High Definition Audio. Line-in, Line-out, Mic-in
Power & battery
Power
Input PWR: 12V DC-In
Power On: AT/ATX supported
AT: Direct PWR on as power input ready
ATX:Press button to PWR on after power input ready
Physical & build
Form Factor Dimensions
Pico-ITX (3.9-in x 2.8-in x 0.76-in, 10 cm x 7.2 cm x 1.93 cm)
Form Factor
Pico-ITX SBC
Other
BIOS
AMI SPI 256 Mbit
Rear I/O DC Jack
1
Watchdog Timer Output
From Super I/O to drag RESETCON#
Watchdog Timer Interval
256 Segments, 0, 1, 2, ...255sec
Operating Temp
20ºC ~ 70ºC
Operating Humidity
5% ~ 90%

I/O Ports 6

  • High Definition Audio. Line-in
  • Line-out
  • Mic-in
  • 1x HDMI 2.0b
  • 1x 2.5 Gigabit LAN
  • 1x USB 3.2 Gen2 (Type A)
