ProcessorQualcomm
Memory1 GB LPDDR4
Storage8 GB eMMC
OSLinux
Weight1.6 lb
Specifications 116 normalized
Processor
- Processor
- Qualcomm
- AWS IoT Core
- Utility to interact with the AWS cloud platform. Jobs Support: Call the device's API using AWS Jobs functionality
Memory & storage
- Memory
- 1 GB LPDDR4
- FLASH storage
- 8 GB eMMC
Connectivity
- Networking
- 1 x LAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
- WAN/LAN
- 1 x WAN/LAN port, 10/100/1000/2500 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
- Wireless mode
- 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Dual Band, 2x2 MIMO, Access Point (AP)
- Wi-Fi security
- WPA-PSK, WPA2-PSK, WPA3-SAE, WPA-EAP, WPA2-EAP, WPA3-EAP, OWE
CCMP, TKIP ciphers - Wi-Fi users
- Up to 128 simultaneous connections
- Wireless QR code generator
- Once scanned, a user will automatically enter your network without needing to input login information
- Physical Interfaces: Power
- Power/WLAN Button
- SIM PIN code management
- SIM PIN code management enables setting, changing, or disabling the SIM card's PIN
- Network protocols
- TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)
- Connection monitoring
- Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
- Network topology
- Visual representation of your network, showing which devices are connected to which other devices
- Network backup
- Mobile, VRRP, Wired options, each of which can be used as an automatic Failover
- Supported connection types
- IP, USB
- OPC UA: Supported connection types
- TCP
- MODBUS: Supported connection types
- Client
- DNP3: Supported connection types
- TCP, USB
- DLMS/COSEM: Supported connection types
- TCP
- Teltonika Networks Web API (beta) support
- Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation:
- SIM
- 1 x SIM slots (Nano SIM - 4FF)
- USB
- 1 x Virtual network interface via micro USB
Power & battery
- Power Consumption
- Idle: < 8 W, Max: < 24 W
- Power
- 1 x Barrel socket
Physical & build
- Weight
- 720 g
- Dimensions (W x H x D)
- Ø 100 mm x 185 mm
- Casing material
- Plastic panels
Operating system & software
- Operating System
- RutOS (OpenWrt based Linux OS)
Security
- Security: Firewall
- Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64
Warranty & support
- VoIP passthrough support
- H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
- Supported modes
- Router
- OPC UA: Supported modes
- Client, Server
- MODBUS: Supported modes
- Server, Client
- Supported data formats
- 8-bit: INT, UINT
16-bit: INT, UINT (MSB or LSB first)
32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII - DNP3: Supported modes
- Station, Outstation
- DLMS Support
- DLMS - standard protocol for utility meter data exchange
- DLMS/COSEM: Supported modes
- Client
- Site Manager: Supported modes
- Manager
- Supported languages
- Busybox shell, Lua, C, C++
Other
- Mobile module
- 5G NR up to 4.0 Gbps DL / 900 Mbps UL
4G LTE (CAT 19) up to 1.6 Gbps DL / 200 Mbps UL
3G – 42 Mbps DL, 5.76Mbps UL - 3GPP Release
- Release 17
- Status
- IMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
- SMS
- SMS status, SMS configuration, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
- USSD
- Supports sending and reading Unstructured Supplementary Service Data messages
- Block/Allow list
- Operator block/allow list (by country or separate operators)
- Band management
- Band lock, Used band status display
- APN
- Auto APN
- Bridge
- Direct connection (bridge) between mobile ISP and device on LAN
- Passthrough
- Router assigns its mobile WAN IP address to another device on LAN
- Routing
- Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
- Firewall
- Port forward, traffic rules, custom rules, TTL target customization
- Firewall status page
- View all your Firewall statistics, rules, and rule counters
- DHCP
- Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
- DDNS
- Supported >77 service providers, others can be configured manually
- Load balancing
- Balance Internet traffic over multiple WAN connections
- Hotspot
- Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes
- SSHFS
- Possibility to mount remote file system via SSH protocol
- Traffic Management
- Real-time monitoring, wireless signal charts, traffic usage history
- Authentication
- Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
- Attack prevention
- DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
- VLAN
- Port and tag-based VLAN separation
- Mobile quota control
- Custom data limits for SIM card
- WEB filter
- Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
- Access control
- Flexible access control of SSH, Web interface, CLI and Telnet
- Certificate Manager
- Let's Encrypt and SCEP certificate Gen methods
- Open VPN
- Multiple clients and a server can run simultaneously, 27 encryption methods
- OpenVPN Encryption
- DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256
- IPsec
- XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16)
- GRE
- GRE tunnel, GRE tunnel over IPsec support
- PPTP, L2TP
- Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
- Stunnel
- Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program's code
- DMVPN
- Method of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
- SSTP
- SSTP client instance support
- Zero Tier
- ZeroTier VPN client support
- Wire Guard
- WireGuard VPN client and server support
- Tinc
- Tinc offers encryption, authentication and compression in it's tunnels. Client and server support.
- Tailscale
- Tailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol
- Configuration options
- Support for multiple BACnet/IP interfaces, Network number assignment, Preconfigured BDT entries for BBMD (BACnet Broadcast Management Device)
- Custom registers
- MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
- Protocol
- HTTP(S), MQTT, Azure MQTT
- Data to server
- Extract parameters from multiple sources and different protocols, and send them all to a single server
Custom LUA scripting, allowing scripts to utilize the router's Data to server feature - Modbus MQTT Gateway
- Allows sending commands and receiving data from MODBUS Server through MQTT broker
- Functionalities
- Centralized management of TAP access points and Teltonika's managed switches — including device pairing and grouping, FOTA updates, device status monitoring, automatic reboot scheduling with ping/wget health checks, wireless SSID configuration, and VLAN assignment across the site.
- WEB UI
- HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
- FOTA
- Firmware update from server, automatic notification
- SSH
- SSH (v1, v2)
- Monitoring & Management: SMS
- SMS status, SMS configuration
- Call
- Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/off
- Receive email message status alerts of various services
- TR-069
- OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
- MQTT
- MQTT Broker, MQTT publisher
- SNMP
- SNMP (v1, v2, v3), SNMP Trap, Brute force protection
- JSON-RPC
- Management API over HTTP/HTTPS
- RMS
- Teltonika Remote Management System (RMS)
- Thing Worx
- Allows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
- Cumulocity - Cloud of Things
- Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actions.
- Azure IoT Hub
- Can be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
- Firmware/Configuration: WEB UI
- Update FW from file, check FW on server, configuration profiles, configuration backup
- Firmware/Configuration: FOTA
- Update FW
- Firmware/Configuration: RMS
- Update FW/configuration for multiple devices at once
- Keep settings
- Update FW without losing current configuration
- Factory settings reset
- A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
- Development tools
- SDK package with build environment provided
- GPL customization
- You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients' needs
- Package Manager
- The Package Manager is a service used to install additional software on the device
- Input voltage
- 12 VDC
- Telephone
- 1 x RJ11 port
- Status LEDs
- 1 x Power, 1 x Wi-Fi, 2 x Mobile connection type, 2 x LAN status
- Antennas
- 6 x Mobile internal antennas, 2 x Wi-Fi internal antennas
- Reset
- Reboot/User default reset/Factory reset button
- Mounting
- Flat surface placement
- Operating Temperature
- 0 °C to 45 °C
- Operating Humidity
- 5% to 95% non-condensing
- Ingress Protection Rating
- IP30
I/O Ports 4
- LAN: 1 x LAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX c
- WAN/LAN: 1 x WAN/LAN port, 10/100/1000/2500 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports a
- Ethernet: 1 x RJ45 port, 10/100/1000 Mbps, 1 x RJ45 port, 10/100/1000/2500 Mbps
- USB: 1 x Virtual network interface via micro USB
