ProcessorMediaTek MIPS 24KEc
Memory128 MB DDR2
Storage16 MB
OSLinux
Weight0.40 lb
Specifications 62 normalized
Processor
- Processor
- Mediatek, 580 MHz, MIPS 24KEc
Memory & storage
- Memory
- 128 MB, DDR2
- FLASH storage
- 16 MB, NOR Flash
Connectivity
- Networking
- 1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
- Network protocols
- TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SSL/TLS, ARP, SSH, DHCP, SNMP, MQTT
- Connection monitoring
- Ping Reboot, Wget Reboot, Periodic Reboot
- Network topology
- Visual representation of your network, showing which devices are connected to which other devices
- Supported connection types
- RTU (RS232, RS485), TCP
- Teltonika Networks Web API (beta) support
- Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation:
- Physical Interfaces: RS232
- 4-pin in 16-pin terminal block (TX, RX, RTS, CTS)
- Physical Interfaces: RS485
- 4-pin in 16-pin terminal block (D+, D-, R+, R-)
Power & battery
- Power Consumption
- Idle: < 2 W, Max: < 3.5 W
- Power
- 1 x 16-pin terminal block
Physical & build
- Weight
- 180 g
- Dimensions (W x H x D)
- 83 x 25 x 82.6 mm
- Casing material
- Anodised aluminium housing and panels
Operating system & software
- Operating System
- RutOS (OpenWrt based Linux OS)
Warranty & support
- Supported modes
- Server - Receive time from GPS and act as a NTP server to broadcast time for other devices (Stratum 1). Broadcast time through UDP or over Serial (RS232, RS485)
- MODBUS: Supported modes
- Server, Client
- Supported data formats
- 8-bit: INT, UINT
16-bit: INT, UINT (MSB or LSB first)
32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII - Supported languages
- Busybox shell (ash), Lua 5.1, C, C++
Other
- DDNS
- Supported >77 service providers, others can be configured manually
- Authentication
- Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
- WEB filter
- Block list for blocking out unwanted websites, allow list for specifying allowed sites only
- Access control
- Flexible access control of SSH, Web interface, CLI and Telnet
- 802.1x
- Port-based network access control client
- Daytime Protocol
- TCP/UDP
- Date over Serial
- RS232/RS485
- NTP
- NTPv4, NTP authentication (MD5/SHA1), Unicast/Multicast/Broadcast mode
- Protocol
- NTP Stratum 1 Time Server (NTPv4)
- NTP Accuracy
- Ethernet NTP ±1ms overall
- NTP Performance
- >300 NTP requests per second (wire speed)
- Synchronization Accuracy
- LAN synchronization typically 1–10ms
- Custom registers
- MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
- Modbus MQTT Gateway
- Allows sending commands and receiving data from MODBUS Server through MQTT broker
- WEB UI
- HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
- SSH
- SSH (v1, v2)
- SNMP
- SNMP (v1, v2, v3), SNMP Trap, Brute force protection
- JSON-RPC
- Management API over HTTP/HTTPS
- MODBUS
- MODBUS TCP status/control
- Firmware/Configuration: WEB UI
- Update FW from file, check FW on server, configuration profiles, configuration backup
- Keep settings
- Update FW without losing current configuration
- Factory settings reset
- A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
- Development tools
- SDK package with build environment provided
- GPL customization
- You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients' needs
- Acquisition Sensitivity
- Acquisition Sensitivity -146 dBm, Reacquisition Sensitivity -157 dBm, Tracking Sensitivity -157 dBm
- Time Source
- GPS 1575.42 ±1.023 MHz, GLONASS 1597.5–1605.8 MHz, Galileo 1575.42 ±2.046 MHz, BDS 1561.098 ±2.046 MHz
- Startup
- Cold GPS acquisition in <120 seconds
- RS232
- Terminal block connector: TX, RX, RTS, CTS
- RS485
- Terminal block connector: D+, D-, R+, R- (2 or 4 wire interface)
- Input
- 3 x Digital Input, 0 - 6 V detected as logic low, 1 x Analog input, 8 - 30 V detected as logic high
- Output
- 3 x Digital Output, Open collector output, max output 30 V, 300 mA
- Input voltage range
- 9 - 30 VDC, Overvoltage protection, Reverse polarity protection, Surge protection +/- 1kV 50 uS Max
- I/O's
- 3 x Configurable I/O, 1 x Analog input in 16-pin terminal block
- Status LEDs
- 1 x Power, 2x GNSS status LEDs, 1x NTP Server status LED, 3 x IO status LEDs
- Antennas
- 1 x SMA for GNSS
- Reset
- Reboot/User default reset/Factory reset button
- Mounting
- DIN rail, wall mount, flat surface (all require additional kit)
- Operating Temperature
- -40 °C to 75 °C
- Operating Humidity
- 10% to 90% non-condensing
- Ingress Protection Rating
- IP30
- Certifications
- CE, UKCA, CB, UCRF, EAC, WEEE
I/O Ports 7
- LAN: 1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX cross
- RS232: Terminal block connector: TX, RX, RTS, CTS
- RS485: Terminal block connector: D+, D-, R+, R- (2 or 4 wire interface)
- Ethernet: 1 x RJ45 ports, 10/100 Mbps
- I/O's: 3 x Configurable I/O, 1 x Analog input in 16-pin terminal block
- RS232: 4-pin in 16-pin terminal block (TX, RX, RTS, CTS)
- RS485: 4-pin in 16-pin terminal block (D+, D-, R+, R-)
