ProcessorMediaTek MIPS 24KEc
Memory128 MB DDR2
Storage16 MB
OSLinux
Weight0.51 lb
Specifications 102 normalized
Processor
- Processor
- Mediatek, 580 MHz, MIPS 24KEc
Memory & storage
- Memory
- 128 MB, DDR2
- Storage formats
- FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4
- FLASH storage
- 16 MB serial NOR flash
Connectivity
- Networking
- 4 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
- Network protocols
- TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
- Connection monitoring
- Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
- Port management
- View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
- Network topology
- Visual representation of your network, showing which devices are connected to which other devices
- Network backup
- VRRP, Wired options, each of which can be used as an automatic Failover
- Supported connection types
- TCP
- MODBUS: Supported connection types
- TCP, USB
- BacNET: Supported connection types
- IP, RTU (USB)
- Supported connection
- TCP, USB
- DLMS/COSEM: Supported connection types
- TCP, USB
- Teltonika Networks Web API (beta) support
- Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation:
- USB
- 1 x USB A port for external devices
Power & battery
- Power Consumption
- Idle: < 0.8 W, Max: < 3.8 W
- Power
- 1 x 4-pin power connector
Physical & build
- Weight
- 233 g
- Dimensions (W x H x D)
- 100 x 30 x 85 mm
- Casing material
- Anodised aluminium housing and panels
Operating system & software
- Operating System
- RutOS (OpenWrt based Linux OS)
Security
- Security: Firewall
- Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64
Warranty & support
- VoIP passthrough support
- H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
- Supported modes
- Client, Server
- MODBUS: Supported modes
- Server, Client
- Supported data formats
- 8-bit: INT, UINT
16-bit: INT, UINT (MSB or LSB first)
32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII - BacNET: Supported modes
- Router
- DNP3: Supported modes
- Station, Outstation
- DLMS Support
- DLMS - standard protocol for utility meter data exchange
- DLMS/COSEM: Supported modes
- Client
- Supported languages
- Busybox shell, Lua, C, C++
Other
- WAN
- 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX
- Routing
- Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
- Firewall
- Port forward, traffic rules, custom rules, TTL target customisation
- Firewall status page
- View all your Firewall statistics, rules, and rule counters
- DHCP
- Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
- QoS / Smart Queue Management (SQM)
- Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
- DDNS
- Supported >77 service providers, others can be configured manually
- DNS over HTTPS
- DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
- Load balancing
- Balance Internet traffic over multiple WAN connections
- Hotspot
- Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes
- SSHFS
- Possibility to mount remote file system via SSH protocol
- Traffic Management
- Real-time monitoring, wireless signal charts, traffic usage history
- Authentication
- Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
- Attack prevention
- DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
- VLAN
- Port and tag-based VLAN separation
- WEB filter
- Block list for blocking out unwanted websites, allow list for specifying allowed sites only
- Access control
- Flexible access control of SSH, Web interface, CLI and Telnet
- Certificate Manager
- Certificate creation tool allows to create CA, server, client, let's encrypt, SCEP certificates
- 802.1x
- Port-based network access control server
- Open VPN
- Multiple clients and a server can run simultaneously, 27 encryption methods
- OpenVPN Encryption
- DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192
BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 - IPsec
- XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16)
- GRE
- GRE tunnel, GRE tunnel over IPsec support
- PPTP, L2TP
- Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
- Stunnel
- Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program's code
- DMVPN
- Method of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
- SSTP
- SSTP client instance support
- Zero Tier
- ZeroTier VPN client support
- Wire Guard
- WireGuard VPN client and server support
- Tinc
- Tinc offers encryption, authentication and compression in it's tunnels. Client and server support.
- Custom registers
- MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
- Protocol
- HTTP(S), MQTT, Azure MQTT
- Configuration options
- Support for multiple BACnet/IP interfaces, Network number assignment, Preconfigured BDT entries for BBMD (BACnet Broadcast Management Device)
- Data to server
- Extract parameters from multiple sources and different protocols, and send them all to a single server
Custom LUA scripting, allowing scripts to utilize the router's Data to server feature - Modbus MQTT Gateway
- Allows sending commands and receiving data from MODBUS Server through MQTT broker
- WEB UI
- HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
- FOTA
- Firmware update from server, automatic notification
- SSH
- SSH (v1, v2)
- TR-069
- OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
- MQTT
- MQTT Broker, MQTT publisher
- SNMP
- SNMP (v1, v2, v3), SNMP Trap, Brute force protection
- JSON-RPC
- Management API over HTTP/HTTPS
- RMS
- Teltonika Remote Management System (RMS)
- Cumulocity - Cloud of Things
- Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP. Has reboot and firmware upgrade actions
- Azure IoT Hub
- Can be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
- Firmware/Configuration: WEB UI
- Update FW from file, check FW on server, configuration profiles, configuration backup
- Firmware/Configuration: FOTA
- Update FW
- Firmware/Configuration: RMS
- Update FW/configuration for multiple devices at once
- Keep settings
- Update FW without losing current configuration
- Factory settings reset
- A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
- Development tools
- SDK package with build environment provided
- GPL customization
- You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients' needs
- Package Manager
- The Package Manager is a service used to install additional software on the device
- Data rate
- USB 2.0
- Applications
- Samba share, USB-to-serial
- External devices
- Possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapter
- Input
- Up to 2 x Configurable digital Inputs (shared), 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
- Output
- Up to 2 x Configurable digital Outputs (shared), Open collector output, max output 30 V, 300 mA
- Events
- Email, RMS
- I/O juggler
- Allows to set certain I/O conditions to initiate event
- Input voltage range
- 9 - 30 VDC, reverse polarity protection, voltage surge/transient protection
- PoE (passive)
- Passive PoE (Optional - different hardware required
contact your sales manager) - I/O's
- 2 x Configurable digital I/O on 4-pin power connector
- Status LEDs
- 1 x WAN type LED, 4 x LAN status LEDs, 1 x Power LED
- Reset
- Reboot/User default reset/Factory reset button
- Mounting
- DIN rail, wall mount, flat surface (all require additional kit)
- Operating Temperature
- -40 °C to 75 °C
- Operating Humidity
- 10% to 90% non-condensing
- Ingress Protection Rating
- IP30
I/O Ports 5
- WAN: 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX
- LAN: 4 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX cros
- Ethernet: 5 x RJ45 ports, 10/100 Mbps
- I/O's: 2 x Configurable digital I/O on 4-pin power connector
- USB: 1 x USB A port for external devices
