ViewSonic

TD1655 15.6" Portable 1080p IPS Touch Monitor with 60W USB-C and mini-HDMI

SKUTD1655GTIN766907007077
Size15.6"
Resolution1920 x 1080
PanelIPS
Response time6.5ms
PortsHDMI
Weight2.1 lb

Specifications 58

Display
Screen Size
15.6"
Display Resolution
Full HD (1920x1080)
1920 x 1080
On Screen Display
Image Adjust, Contrast, Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall
Panel Surface
Glossy, Hardness (6H)
Panel Type
IPS
PC Resolution (max)
1920 X 1080
Mac Resolution (max)
1920 X 1080
Colors
262K
Color Space Support
6 bit
Viewing Angles
178º horizontal, 178º vertical
Backlight Life (Hours)
15,000
Response Time (GTG w/OD)
6.5ms
Response Time (Typical GTG)
14ms
Dynamic Contrast Ratio
50,000,000:1
Aspect Ratio
16:9
Brightness
250 cd/m2
Static Contrast Ratio
800:1
Touch Points
10-Point Touch
Touch Technology
Projective Capacitive
Digital Sync
TMDS for miniHDMI (v1.4), Micro-Packet for USB-type C
Contrast ratio
800:1
Viewing angle
178°
Connectivity
USB Type C
60 W x 2
Mini HDMI
1
Ergonomics & build
Stand-by
0.3 W
Cable Organization
No
Tilt (Forward/Back)
0º / 60º
Net Without Stand (lbs)
2.1 lbs
Net Without Stand (kg)
1.0 kg
Physical Without Stand (in.)
14.0 x 8.8 x 0.6
Physical Without Stand (mm)
355.0 x 223.0 x 16.0
Power
Power Supply
Wall type (detachable type-C)
Voltage
AC 100-240V (universal), 50-60 Hz
Camera & audio
Internal Speakers
0.8 W (x2)
Warranty & support
Warranty
Three-year limited warranty on parts, labor and backlight
More details
Viewable Area (in.)
15.6
Light Source
LED
Eco Mode (Conserve)
6.5 W
Eco Mode (optimized)
7.6 W
Consumption (typical)
8.6 W
Consumption (max)
10.5 W
Physical Controls
Up, Down, Left, Right, Power (Push In)
Temperature
32-104º F (0 - 40º C)
Humidity (non-condensing)
20-90%
Frequency Horizontal
15 ~ 82KHz
Frequency Vertical
50 ~ 75 Hz
Regulations
cTUVus, FCC-B, ICES003, Energy Star 8.0, EPEAT Bronze, MX-CoC, Mexico Energy, NRCan
Net (lbs)
2.1 lbs
Gross (lbs)
5.1 lbs
Net (kg)
1.0 kg
Gross (kg)
2.3 kg
Packaging (in.)
17.3 x 11.3 x 3.5
Physical (in.)
14.0 x 8.8 x 0.6
Packaging (mm)
440.0 x 288.0 x 89.0
Physical (mm)
355.0 x 223.0 x 16.0
Package Contents
TD1655 Display, USB type-C to type-C cable, USB type-C to type-A cable, mini HDMI to HDMI Cable (v1.4), Power Adapter, Passive Touch Pen, Quick Start Guide
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Product Sku Group Label
Touch, USB-C 60 W Power Delivery

I/O Ports 1

  • 1x Mini HDMI
