ViewSonic

TD2223 22" 1080p 10-Point Multi IR Touch Monitor with HDMI, VGA, and DVI

SKUTD2223GTIN766907008647
Size22"
Resolution1920 x 1080
PanelTN
Response time5ms
Ports2×USB-A · HDMI 1.4 · Audio
Weight9.9 lb

Specifications 62

Display
Screen Size
22"
Display Resolution
Full HD (1920x1080)
1920 x 1080
On Screen Display
Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Advanced Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)
Panel Surface
Anti-glare, Hard coating 7H
Panel Type
TN
PC Resolution (max)
1920x1080
Mac Resolution (max)
1920x1080
Colors
16.7M
Color Space Support
8 bits
Viewing Angles
170º horizontal, 160º vertical
Backlight Life (Hours)
30,000
Response Time (Typical GTG)
5ms
Aspect Ratio
16:9
Brightness
250 cd/m2
Static Contrast Ratio
1,000:1
Touch Points
10-Point Touch
Touch Technology
Infrared
Contrast ratio
1,000:1
Viewing angle
160°
Connectivity
3.5mm Audio In
1
3.5mm Audio Out
1
USB Type A
2
USB Type B
1
HDMI 1.4 In
1
Kensington Lock Slot
1
Ergonomics & build
Stand-by
0.5 W
Cable Organization
No
VESA Compatible
100 x 100 mm
Tilt (Forward/Back)
22º / 38º
Net Without Stand (lbs)
8.6 lbs
Net Without Stand (kg)
3.9 kg
Physical Without Stand (in.)
20.5 x 12.5 x 2.4
Physical Without Stand (mm)
521.0 x 318.0 x 61.0
Power
Power Supply
Internal
Voltage
AC 100-240V (universal), 50-60 Hz
Camera & audio
Internal Speakers
2 W (x2)
Warranty & support
Warranty
Three-year limited warranty on parts, labor and backlight
More details
Viewable Area (in.)
22
Light Source
LED
VGA
1
DVI-D
1
Eco Mode (Conserve)
11 W
Eco Mode (optimized)
13 W
Consumption (typical)
15 W
Consumption (max)
19 W
Physical Controls
1,2,3,4,5,6 (Power)
Temperature
32-104º F (0 - 40º C)
Humidity (non-condensing)
20-90%
Frequency Horizontal
24 ~ 82 KHz
Frequency Vertical
50 ~ 75 Hz
Regulations
cTUVus, FCC-B, ICES003, Energy Star, EPEAT, MX-CoC, Mexico Energy
Net (lbs)
9.9 lbs
Gross (lbs)
13.2 lbs
Net (kg)
4.5 kg
Gross (kg)
6.0 kg
Packaging (in.)
22.8 x 15.9 x 6.5
Physical (in.)
20.5 x 13.1 x 4.0
Packaging (mm)
580.0 x 405.0 x 164.0
Physical (mm)
521.0 x 334.0 x 101.0
Package Contents
TD2223 Display, Power Cable, USB Type B Uplink Cable, Quick Start Guide
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Product Sku Group Label
22 Inch

I/O Ports 7

  • 2x USB Type A
  • 1x USB Type B
  • 1x 3.5mm Audio In
  • 1x 3.5mm Audio Out
  • 1x VGA
  • 1x DVI-D
  • 1x HDMI 1.4 In
