ViewSonic

TD2230 22" 1080p IPS 10-Point Multi Touch Monitor with HDMI, DP, and VGA

SKUTD2230GTIN766907842418
Size22"
Resolution1920 x 1080
PanelIPS
Response time14ms
Ports2×USB-A · HDMI · DP · Audio
Weight7.9 lb

Specifications 60

Display
Screen Size
22"
Display Resolution
1920 x 1080
On Screen Display
Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)
Panel Surface
Anti-glare, Hard coating 7H
Panel Type
IPS
PC Resolution (max)
Up to 1920x1080 non-interlaced
Mac Resolution (max)
Up to 1920x1080
Colors
16.7M
Viewing Angles
178º horizontal, 178º vertical
Backlight Life (Hours)
30,000
Response Time (Typical GTG)
14ms
Dynamic Contrast Ratio
50,000,000:1
Brightness
250 cd/m2
Static Contrast Ratio
1,000:1
Display Port
1
Touch Points
10-Point Touch
Touch Technology
Capacitive
Analog Sync
Separate Sync, Composite Sync, Sync on Green, TMDS, PCI-E
Contrast ratio
1,000:1
Viewing angle
178°
Connectivity
3.5mm Audio In
1
3.5mm Audio Out
1
USB Type A
2
USB Type B
1
HDMI In
1
Ergonomics & build
Cable Organization
No
VESA Compatible
100 x 100 mm
Tilt (Forward/Back)
20º~70º, lay flat
Net Without Stand (lbs)
7.9 lbs
Net Without Stand (kg)
3.6 kg
Physical Without Stand (in.)
19.3 x 11.8 x 1.9
Physical Without Stand (mm)
490.3 x 298.8 x 47.3
Power
Power in
DC 19V/2.37A
Voltage
AC 100-240V (universal), 50-60 Hz
Camera & audio
Internal Speakers
3 W (x2)
Warranty & support
Warranty
Three-year limited warranty on parts, labor and backlight
More details
Viewable Area (in.)
21.5
Light Source
LED
VGA
1
Eco Mode (Conserve)
16 W
Eco Mode (optimized)
18 W
Consumption (typical)
25 W
Consumption (max)
28 W
Physical Controls
1, 2, Down, Up, Power
Temperature
32-104º F (0 - 40º C)
Humidity (non-condensing)
20-90%
Frequency Horizontal
24~82kHz
Frequency Vertical
50~76 Hz
Regulations
cULus, FCC-B w/ICES003, Enery Star 7.0, DOE EPEAT, UL-MX-CoC, Mexico Energy
Net (lbs)
7.9 lbs
Gross (lbs)
10.4 lbs
Net (kg)
3.6 kg
Gross (kg)
4.7 kg
Packaging (in.)
21.7 x 14.6 x 4.5
Physical (in.)
19.3 x 11.8 x 5.1
Packaging (mm)
550 x 371 x 114
Physical (mm)
490.3 x 298.8 x 129.7
Package Contents
TD2230 monitor, Power cable, Power adapter, HDMI cable, USB 3.0 cable, Audio cable, Quick Start Guide, ViewSonic Wizard CD
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Product Sku Group Label
22 Inch

I/O Ports 7

  • 2x USB Type A
  • 1x USB Type B
  • 1x 3.5mm Audio In
  • 1x 3.5mm Audio Out
  • 1x HDMI In
  • 1x VGA
  • 1x DisplayPort
