ViewSonic

TD2423d 24" 1080p 10-Point Multi IR Touch Monitor with HDMI, VGA, and DP

Out of stock
SKUTD2423dGTIN766907011685
Size24"
Resolution1920 x 1080
PanelMVA
Response time7ms
Ports2×USB-A · HDMI 1.4 · DP · Audio
Weight11.5 lb

Specifications 59

Display
Screen Size
24"
Display Resolution
Full HD (1920x1080)
1920 x 1080
On Screen Display
Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Advanced Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)
Panel Type
MVA
Colors
16.7M
Color Space Support
8 bits
Viewing Angles
178º horizontal, 178º vertical
Backlight Life (Hours)
30,000
Response Time (Typical GTG)
7ms
Aspect Ratio
16:9
Brightness
250 cd/m2
Static Contrast Ratio
3,000:1
Display Port
1
Touch Points
10-Point Touch
Touch Technology
Infrared
Contrast ratio
3,000:1
Viewing angle
178°
Connectivity
3.5mm Audio In
1
3.5mm Audio Out
1
USB Type A
2
USB Type B
1
HDMI 1.4 In
1
Kensington Lock Slot
1
Ergonomics & build
Stand-by
0.5 W
Cable Organization
No
VESA Compatible
100 x 100 mm
Tilt (Forward/Back)
22º / 38º
Net Without Stand (lbs)
10.3 lbs
Net Without Stand (kg)
4.7 kg
Physical Without Stand (in.)
22.5 x 13.7 x 2.4
Physical Without Stand (mm)
571.0 x 348.0 x 61.0
Power
Power Supply
Internal
Voltage
AC 100-240V (universal), 50-60 Hz
Camera & audio
Internal Speakers
2 W (x2)
Warranty & support
Warranty
Three-year limited warranty on parts, labor and backlight
More details
Viewable Area (in.)
24
Light Source
LED
VGA
1
Eco Mode (Conserve)
14 W
Eco Mode (optimized)
16 W
Consumption (typical)
18 W
Consumption (max)
21.5 W
Physical Controls
1,2,3,4,5,6 (Power)
Temperature
32-104º F (0 - 40º C)
Humidity (non-condensing)
20-90%
Frequency Horizontal
24 ~ 82 KHz
Frequency Vertical
50 ~ 75 Hz
Regulations
cTUVus, FCC-B, ICES003, Energy Star, EPEAT, MX-CoC, Mexico Energy
Net (lbs)
11.5 lbs
Gross (lbs)
15.4 lbs
Net (kg)
5.2 kg
Gross (kg)
7.0 kg
Packaging (in.)
25.4 x 16.6 x 6.5
Physical (in.)
22.5 x 13.7 x 4.0
Packaging (mm)
6445.0 x 422.0 x 166.0
Physical (mm)
571.0 x 348.0 x 101.0
Package Contents
TD2423d, Power Cable, HDMI cable, USB Type B Uplink Cable, Quick Start Guide
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Product Sku Group Label
24 Inch

I/O Ports 7

  • 2x USB Type A
  • 1x USB Type B
  • 1x 3.5mm Audio In
  • 1x 3.5mm Audio Out
  • 1x VGA
  • 1x HDMI 1.4 In
  • 1x DisplayPort
