Grandstream
GWN7806(P)
Ports48 ports
Port speed1G
PoE budget400 W · 48 ports
Switching capacity108Gbps
Weight8.8 lb
Specifications 13
Ports & interfaces
- Gigabit Ethernet Ports
- 48
- Gigabit SFP/SFP+ Ports
- 6 SFP+ Ports
- PoE Ports (PoE Models Only)
- 48
Performance
- Switching
- 32K MAC addresses, including static, dynamic, filtering and sticky MAC address 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, protocol-based VLAN, QinQ Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI 32 VLAN virtual interface with 9216 MTU 1K ARP/NDP GVRP(pend
- Total Non-Blocking Throughput
- 108Gbps
- Switching Capability
- 216Gbps
- Forwarding Rate
- 160.704Mpps
Power & PoE
- Total PoE Output Power (PoE Models Only)
- 400 W (30 W per Port)
Management & software
- Network Protocol
- IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
- Security
- User hierarchical management and password protection, HTTPS, SSH, Telnet Identity authentication including 802.1X and MAC authentication AAA authentication including RADIUS, TACACS+ Storm control Port isolation, port security, sticky MAC Filtering MAC address IP/IPv6 source guard, DoS attack prevent
Physical & environment
- Weight
- 4 kg
- Dimensions
- 440 × 301 × 44 mm
- Temperature
- 0 °C to 45 °C
