Lenovo ThinkSystem SR850 V4

ProcessorTwo or four Intel Xeon 6
Memory16 TB

Specifications 14 normalized

Processor
Processor
Two or four Intel Xeon 6 processors, up to 350W Mesh topology with 3x UPI links Up to 4x QAT, DLB, IAA and DSA Accelerators
Memory & storage
Memory
Up to 16 TB of TruDDR5 memory in 64x slots Memory speeds up to 6400 MHz Supports CXL 2.0 memory in E3.S 2T form factor, up to 12x DIMMs with four processors
Storage
Up to 32x E3.S 1T direct NVMe drives or up to 24x 2.5&quot
drives Supports up to 24x direct connection NVMe drives, and up to 2x M.2 drives for boot
Graphics
GPU Support
Up to 2x double-width 400W GPUs or 4x single-width 75W GPUs
Connectivity
Expansion
Up to 12x (11x Gen5 + 1x Gen4) or 9x (7x Gen5 + 2x Gen4) expansion slots Front: 2x USB 3.0, 1x Mini-DP Rear: 2x USB 3.1, optional Serial port, VGA port, 1GbE dedicated management port
Network Interface
2 Dedicated OCP 3.0 slots supporting 1GbE, 10GbE, 25GbE, 100GbE, 200GbE or 400GbE
Power & battery
Power
2x Platinum or Titanium hot-swap power supplies N+N redundancy supported
Physical & build
Form Factor
2U
Operating system & software
OS Support
Microsoft Red Hat SUSE VMware Visit lenovopress.com/osig for more information
Security
Security
Root of Trust (RoT) module includes Platform Firmware Resiliency (PFR) Trusted Platform Module (TPM) 2.0 or TCM for PRC, and optional Chassis Intrusion Switch that secures and authenticates the system to prevent unauthorized intrusion. Optional locking security bezel to prevent unauthorized access to colocation facilities.
Warranty & support
RAID Support
Support for ThinkSystem PCIe RAID/HBA cards
Limited Warranty
1-year and 3-year customer replaceable unit and onsite service Next business day 9x5 Optional: service upgrades
Other
High Availability
Predictive Failure Analysis (PFA) Hot-swap/redundant drives and power supplies Redundant fans Internal light path diagnostic LEDs Front-access diagnostics via dedicated USB port Optional External Diagnostics Panel Handset with LCD display
Management
Lenovo XClarity Controller Redfish support
