ProcessorMediaTek Cortex A53 · 2C
Memory1 GB DDR4
Storage8 GB eMMC
OSLinux
Weight1.0 lb
Specifications 195 normalized
Processor
- Processor
- Mediatek, 1.3 GHz, Dual-core ARM Cortex A53
Memory & storage
- Memory
- 1 GB DDR4
- Storage formats
- FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4
- FLASH storage
- 16 MB serial NOR flash, 8 GB eMMC Flash
Connectivity
- Wake On LAN
- Allows waking up a network device from sleep mode, supports Broadcast, wake on boot, wake all saved devices
- Networking
- 5 x RJ45 ports, 10/100/1000 Mbps
- Network Type Management
- Offers the ability to lock different network types
- Port Mirroring
- Mirror incoming and outgoing packets
- Port Forward
- By port/protocol/IP address, NAT loopback
- Network protocols
- IPv4, IPv6, ARP, IPsec, PPP, IP NAT
- Ports Control
- View, enable, disable, auto-configuration control, transmission speed control
- SIM
- 2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders
- SIM Idle Protection
- Ensures periodic activation of unused SIM slots to prevent SIM card blocking
- Network: Status
- LAN networks, DHCP leases, Firewall rules and policies, IPv4/IPv6 routes, ARP table, IPv6 neighours
- Network Traffic Control
- Traffic control does packet prioritizing, traffic shaping, bandwidth limiting, AQM (Active Queue Management) and QoS (Quality of Service)
- SIM PIN/PUK Code Management
- Enables setting, changing, or disabling the SIM card's PIN/PUK codes
- Modem Debug
- Enable access to modem debug with AT commands
- SIM switch
- Enables automatic switching between SIM card slots based on user-configured criteria
- USB
- 1 x USB A port for external devices
Power & battery
- Power Consumption
- < 5 W
- Power
- 1 x 4-pin power connector
Physical & build
- Weighted Fair Queue
- Weighted Fair Queue performs bandwidth distribution by class weights and priorities for network traffic
- Weight
- 452 g
- Dimensions
- 103.4 x 42.6 x 130.4 mm
- Casing material
- Aluminium housing
Operating system & software
- Operating System
- RutOS (Linux based OS)
- Server software
- TAVL, RMS
- Software Development Kit (SDK)
- SDK archive with a build environment. Add new custom applications and libraries to an image, modify an existing component, create custom-branded firmware and web page application by changing colors, logos and other elements to fit your or your clients' needs
Security
- TPM
- Identification and authentication module, TPM 2.0 standard
Warranty & support
- I/O Service
- Hardware input/output control
- CIFS Client Support
- Enables mounting remote CIFS/SMB network shares as a client, allowing access to files on Windows servers or Samba shares
- Supported languages
- Busybox shell (ash), Lua 5.1, C, C++, Python
Other
- Troubleshoot
- System diagnostic and troubleshooting tools
- Mounting
- DIN rail, wall mount, flat surface (all require additional kit)
- Internet Status
- IPv6/IPv6 track IP, interval configuration
- Hotspot
- Captive portal (Hotspot), internal/external Radius server, SMS/SSO/MAC authorisation, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes and option to upload and download customised hotspot themes
- SMS Utilities
- Rules that perform certain actions when they are activated by SMS messages
- Status
- IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, mobile signal graphs, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
- NTP
- Provides system time synchronization with NTP servers, GSM network, GPS, and supports operation as a local NTP server to distribute time to network clients
- Wire Guard
- VPN that and was designed with the goals of ease of use, high speed performance, and low attack surface
- DLMS/Cosem
- Client mode with HDLC, Wrapper and IEC 62056-21(mode E) interfaces over TCP connections
- Configuration Profiles
- Switching between multiple profiles, profile scheduler
- OPC UA
- Client and Server modes for industrial data exchange
- Block/Allow list
- Offers operator block/allow listing by country or individual operators
- Band management
- Provides mobile band locking for different network types
- APN Database Management
- Enables access to add, delete or edit records of APN database for auto APN functionality
- Transport Protocols
- TCP, UDP, ICMP, GRE, ESP, RIP, OSPF, BGP, IPsec
- MPLS
- LDP, L3VPN
- Geofencing
- Configurable multiple geofence zones
- SMTP
- Comunnication protocol used for sending and relaying emails between mail servers over the Internet
- IEC 60870-5
- Client and Server modes over IEC 60870-5-104 (TCP)
- Socat
- Bidirectional data relay between two byte streams
- NMEA
- 0183 standard
- Failover
- Switch automatically and seamlessly to a reliable backup connection
- Data to server
- Device, manufactoring information, MQTT, Lua script, GSM, Mobile usage, DLMS, DNP3, Impulse Counter, Modbus, Modbus alarms, OPC UA, SMS, I/O and GPS data inputs
HTTP, MQTT, SMS, FTP, SMTP, Socket, Lua script and Azure IoT Hub servers - SCEP
- SCEP (Simple Certificate Enrollment Protocol) is a standard protocol used for the automated issuance and management of digital certificates
- 2FA
- Support for configuring external 2FA providers
- Scheduler
- Can be used to configure a timetable of when an I/O pin state should change, based on days of the week or month and hours of the day.
- VRF
- Virtual routing and forwarding, IP technology allows users to configure multiple routing table instances to simultaneously co-exist within the same router
- IP Block
- Blocks IP addresses after a configured number of unsuccessful authorisation attempts, supports timed or permanent blocking
- Azure IoT Hub
- Data to Server support, direct method support, plug & play integration, DPS
- DHCPv4
- Status, server mode, relay mode, custom DHCP options, static leases
- VLAN
- Tagged, untagged
- Dynamic Route Protocols
- RIP, OSPF, EIGRP, BGP, NHRP
- DNS
- Caching DNS server, DNS forwardings, rebind protection, static DNS entries
- DS-lite
- Dual-Stack Lite B4 configuration
- Operating Humidity
- 10% to 90% non-condensing
- Telnet
- Telnet is a network protocol used to connect to remote machines and manage them through network
- Targets
- Accept, drop, reject, do not track, mark, change TTL, change DSCP
- OSPFv3
- OSPFv3 routing engine (installed as package)
- Certificate Manager
- Certificate creation tool allows to create CA, server, client, let's encrypt, SCEP certificates
- Input voltage range
- 9-50 VDC, reverse polarity protection, surge protection >51 VDC 10us max
- Data rate
- USB 2.0
- SSHFS
- SSHFS filesystem client for mounting remote directories over a Secure Shell connection
- L2 TPv3
- Tunneling protocol that can be used as an alternative protocol to Multiprotocol Label Switching (MPLS) for encapsulation of multiprotocol Layer 2 communications traffic over IP networks
- USSD
- Ensures sending and reading Unstructured Supplementary Service Data messages
- SMPP
- SMPP protocol services for flexible short message data transfer
- IPtables Filter Extension
- IPtables extensions for extra NAT targets. Adds targets: MIRROR and NETMAP
- IPsec
- Tunnel, Transport, XFRM modes, Pre-shared key, X.509, PKCS#12, EAP, XAUTH, RSA authentication methods, IKEv1, IKEv2, 14 encryption methods, MD5, SHA1, SHA256, SHA348, SHA512 authentication algorithms
- Vo LTE
- Provides control of VoLTE service
- Auto Reboot
- Periodic device reboot and automatic reboot on failed ping/wget requests, device reboot, modem reboot
- APN
- Implemented automatic APN selection with the option for manual APN configuration
- I Perf3
- A tool for performing network throughput measurements
- MQTT Publisher
- Client instance that can send messages to the Broker, who can forward these messages to other clients (subscribers)
- Module
- 5G Sub-6 GHz SA/NSA 2.5/3.4Gbps DL (4x4 MIMO), 900/460Mbps UL (2x2 MIMO)
4G LTE CAT 19 DL 1.6Gbps, CAT18 UL 211Mbps
3G HSPA+ Rel8 DL/UL 42/11Mbps - Events Reporting
- Notification sending to email and SMS
- UPNP
- ACLs, secure mode, additional logging
- Tables
- Raw, mangle, nat, filter
- Web UI
- Graphical interface that allows users to interact with system through a web browser
- Dynamic DNS
- 77 service providers, others can be configured manually
- MQTT Broker
- System which coordinates messages between different clients
- External devices
- Possibility to connect external HDD, flash drive, printer, USB-serial adapter
- Package Manager
- Download/upgrade from server, offline upload
- VTYSH
- Command line interface for dynamic route protocols
- Traffic Rules
- Time-based restrictions, input/output/forward control, by protocol/port/IP address/MAC address
- Status LEDs
- 4 x WAN status LEDs, 3 x Mobile connection type, 3 x Mobile connection strength, 8 x LAN status, 1 x Power, 2 x WAN status
- Tinc
- VPN that uses tunnelling and encryption to create a secure private network between hosts on the Internet
- Speedtest
- Provides a quick snapshot of Internet connection speed performance
- SMS Forwarding
- To HTTP, SMS and Email
- Stunnel
- Proxy designed to add TLS encryption functionality to existing clients and servers
- Eo IP
- Ethernet over IP (EoIP) tunnelling is a protocol based on GRE RFC 1701 that creates an Ethernet tunnel between two routers on top of an IP connection
- Coordinates
- GNSS coordinates via WebUI, SMS, TAVL, RMS, API
- Messages
- Sending and reading of SMS messages
- eSIM Management
- Management of eSIM profiles, including downloading and deleting operations, tracking and executing pending notifications and parsing of eSIM ID
- E SIM
- Consumer type eSIM (SGP.22), up to 7 eSIM profiles
- 3GPP Release
- Release 16
- Docker
- Open-source platform that enables developers to build, deploy, run, update and manage containers
- NAT Rules
- Source NAT, destination NAT, PAT, static NAT, dynamic NAT, NAT mapping
- Multi Language
- Change the WebUI language from English to German, Turkish, Spanish, Portuguese, Japanese, Ukrainian, Polish or French
- Operating Temperature
- -40 °C to 75 °C
- SMS Limit
- Offers control over the number of SMS messages that can be sent within a certain period
- Smart Queue Management
- Smart Queue Management performs per-packet/per flow network scheduling, active queue length management (AQM), traffic shaping/rate limiting, and QoS (prioritisation)
- Firmware From Server (FOTA)
- Download suggested firmware from server
- GRE
- Tunnel, GRE tunnel over IPSec modes
- NAT64
- NAT64 is an IPv6 transition mechanism that facilitates communication between IPv6 and IPv4 hosts by using a form of network address translation
- PPTP
- Server, client
- Events Log
- Centralized log viewer for main system and service events
- Input
- 1 x Digital Input, 0-6 V detected as logic low, 8-50 V detected as logic high
- Static multicast routes
- Support for configuring static multicast routes, TTL filters
- Module Firmware Update From Server
- Mobile module firmware update from server
- Traffic Logging
- Netfilter userpace logging that provides the ability to set up periodic transfers of the selected traffic log to an FTP server
- Multiple PDN
- Enables the use of different PDNs for multiple network access and services
- GNSS
- GPS, GLONASS, BeiDou, Galileo and QZSS
- CLI
- Command line interface in Web
- Thing Worx
- Network and mobile parameters monitoring
- Single Sign-On
- Support for configuring OpenID Connect providers
- Privileged Access Management (PAM)
- Authorisation service priority, external users support, required/requisite/sufficient/optional types
- Call Utilities
- Rules that perform certain actions when they are activated by a call
- Firewall
- IPv4, IPv6, connection tracking, routing/NAT offloading, statefull firewall, logging, zone based firewall, custom rules, DMZ, firewall statistics, rules list, tables list
- API
- REST API, HTTP/HTTPS protocol, GET/POST/PUT/DELETE methods, bulk requests, Session token and HTTP basic authentication methods, ACLs. Documentation:
- IPtables NAT extra
- IPtables extensions for packet content inspection. Includes support for: Matches: - string - bpf
- Netbird
- Open-source VPN management platform built on top of WireGuard making it easy to create secure private networks for your organization or home
- DHCPv6
- Status, server mode, statless mode, statefull mode, relay mode, hybrid mode, Router advertisement service, NDP proxy, static leases
- Attack prevention
- DDOS prevention, SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention, port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
- Passthrough Mode
- Router assigns it's mobile WAN IP address to another device on LAN
- Output
- 1 x Digital Output, Open collector output, max output 50 V, 300 mA
- DMVPN
- Spoke and Hub modes, GRE, IPSec, NHRP technologies
- SNMP
- Available versions v1, v2 and v3, Signal strength, network type, Input/Output and events log notifications traps
- Zero Tier
- VPN which offers peer-to-peer mesh connections
- SSTP Client
- SSTP client is a is a VPN tunnel that provides a mechanism to transport PPP traffic through an SSL/TLS channel
- Open Connect
- Cross-platform multi-protocol SSL VPN client which supports a number of VPN protocols
- PoE standards
- Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9-50 VDC
- Speed
- 5 x 10/100/1000 Mbps
- MODBUS
- Client, Server and MQTT Gateway modes with 14 data types over TCP connections
- Backup
- Tool for creating and restoring configuration backups
- Open VPN
- Client and server modes, Tunnel (TUN) or Bridged (TAP) types, NordVPN, ExpressVPN external providers static key, TLS, password, PKCS#12 authentication methoods, 27 encryption methods
- Deny Data on Roaming
- Offers mobile data prohibition when module registers on a roaming network
- Realtime Data
- CPU utilisation, data usage and history, active network connections, real time mobile signal strength values, mobile data usage values over different periods of time
- 802.1X Client
- MD5, TLS, PWD, Tunneled TLS, PEAP
- Topology
- Displays network devices that belong to the same network
- Antennas
- 4 x SMA for Mobile, 1 x SMA for GNSS
- SSH
- Network protocol that enables secure communication between two computers over an unsecured network
- UDP Relay
- UDP relay forward broadcast packets from a specified UDP port to configured interface
- Email to SMS
- Connects to your email account and checks its inbox at the specified frequency. If it finds any new received emails with a specific subject (phone number in email subject), it sends the body of the email as an SMS message(s) to the recipient specified in the email subject field.
- LED Management
- Provides services for controlling hardware LEDs
- Standard
- Compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
- I/O juggler
- Utility to create automated rules that perform certain actions based on Input state changes and other conditions
- Ingress Protection Rating
- IP30
- NTPD
- Utility with advanced NTP features which includes NTPv4
- RMS
- Teltonika Remote Management System
- TR-069
- Device reboot, firmware upgrade and configuration setting, Device, network and mobile monitoring parameters
- Input/Output: Status
- Control and monitor the current I/O pin status
- IGMP Proxy
- IGMP proxy (Multicast routing) forwards multicast traffic using IGMP signalling
- WEB filter
- Helps control access to Internet web pages, supports blocklist or allowlist
- Load balancing
- Distribute traffic among multiple WAN connections to improve performance and reliability
- Free RADIUS
- One of the top open source RADIUS servers, can be used as an Authentication Server in 802.1X and therefore for WPA/WPA2/WPA3 Enterprise setup
- JSON-RPC
- Remote procedure call (RPC) system configuration protocol
- Tcpdump
- Incoming/Outgoing Internet packet analyzer for troubleshooting connectivity issues
- BFD
- Peers, profiles, receive and transmit interval, passive mode
- Low Signal Reconnect
- Ensures mobile data reconnection in case of poor signal
- Event Juggler
- Device boot, time, Hotspot connections, astronomical time, device logs events, GPS events, GSM, mobile data limit events, Input/output events Connection management, MQTT message, Email, HTTP request, Lua and other script execution, RMS management, profile change, device reboot actions, SMS, call, modem restart actions, SIM switch actions, Output management actions
- DNS over HTTPS
- DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
- Bridge Mode
- Direct connection (bridge) between mobile ISP and device on LAN
- AWS
- Call device's API by using AWS Jobs functionality
- Operator Selection Modes
- Module connection modes including auto, manual, and manual-auto
- Routing
- Static routing, policy based routing, routing rules, dynamic routing
- IO
- 1 x Digital Input, 1 x Digital Output on 4-pin power connector
- 7-zip
- Minified 7-zip archiver with 7z archive and AES-256 encryption
- Mobile data limit
- Provides warnings about limit and control to used data within customizable period
- Emailrelay
- Lightweight SMTP store-and-forward mail server, supports Server, Proxy, Command line modes
- DNP3
- Station and Outstation modes over TCP connections
- VRRP
- Virtualized MAC, Priority, advertisement interval
- Impulse Counter
- Impulse counting on selected I/O pins with persistent storage
- Bacnet
- Router mode over connections
- Conntrack Helpers
- FTP, PPTP, SIP, SNMP, TFTP, IRC
- L2 TP
- Server, client, L2TP over IPSec, IPv6 support
- VXLAN
- 16 million VNIs, L2 over L3 tunneling, multicast, unicast or broadcast
- Starlink management
- Status, stow/unstow/reboot actions
- Bridging
- Multiple bridges, STP, IGMP snooping (Multicast)
- Tailscale
- Zero config VPN for building secure networks
- Multiple Users
- Multiple Web users with configurable access permissions
- HTTP/HTTPS
- HTTP and HTTPS protocols used for communication between web browsers and devices
- Auto Reply
- Automatic replying to SMS messages that the device receives
- Cumulocity / Cloud of Things
- Reboot and firmware upgrade actions
device, network and mobile parameters monitoring - 802.1X Server
- Port-based multi-host 802.1X NAC, RADIUS-assigned VLANs, accept VLANs, reject VLANs
I/O Ports 2
- Ethernet: 5 x RJ45 ports, 10/100/1000 Mbps
- USB: 1 x USB A port for external devices
Price history
loading…
