802.1p class of service, 802.1x port-based network access control, 802.1Q VLAN
Port aggregation
802.3ad (LACP)
Port Settings
Enable/disable, link speed control, port isolation, PoE Management, EEE (802.3az) management, Port Mirroring
Teltonika Networks Web API (beta) support
Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation:
PoE+ ports
Ports 1-24
Physical Interfaces: Fiber
4 x SFP ports
Power & battery
Total PoE Power Budget (at PSE)
300 W
Power Consumption
Idle: 9 W / Max: 330 W / PoE Max: 300
Power
1 x C14 connector
Physical & build
Weight
2291 g
Dimensions (W x H x D)
483 x 44 x 234 mm
MAC address table size
8K entries
Casing material
Anodised aluminium housing and panels
Cooling type
Active
Operating system & software
Operating System
SwmOS (OpenWrt based Linux OS)
Warranty & support
MAC filtering support
Allow specific MAC addresses to connect through specified ports, ignore unauthorized or disable the port if an unauthorized MAC address is detected
Supported languages
Busybox shell, Lua, C, C++
Jumbo frame support
10000 bytes
Other
Fiber
4 x SFP ports
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az, 802.3ad
ETH
Multi-layer managed 24 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
Profinet
Profinet Class B conformance (available with optional order code)
SNMP V2, V3
Yes
LLDP
Yes
Routing
Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP)
MRP
MRP client role, MRP manager role
L2 features
Loop protection, Forwarding table, VLAN, STP/RSTP
DHCP
DHCP server, DHCP client, DHCP static leases capable of using MAC with wildcards
