Weight0.31 lb
Specifications 26 normalized
Connectivity
- Networking
- 5 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover
- Physical Interfaces: Ethernet
- 5 x RJ45 ports, 10/100 Mbps
- PoE Max Power per Port (at PSE)
- 30 W
- PoE ports
- Port 1- 4
Power & battery
- Total PoE Power Budget (at PSE)
- 120 W
- Power Consumption
- Idle: 1 W / Max: 1.5 W / PoE Max: 121 W
- Power
- 1 x 3-pin industrial DC power socket
Physical & build
- Weight
- 142 g
- Dimensions (W x H x D)
- 113 x 28 x 50 mm
- MAC address table size
- 2K entries
- Casing material
- Anodised aluminium housing and panels
Warranty & support
- Jumbo frame support
- 9216 bytes
Other
- IEEE 802.3 series standards
- 802.3i, 802.3u, 802.3x, 802.3az, 802.3p 802.3Q
- Profinet
- Profinet Class A conformance (available with optional order code)
- PoE standards
- IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2), Alternative A
- Bandwidth (Non-blocking)
- 10 Gbps
- Packer buffer
- 128 KB
- Input voltage range
- 7 – 57 VDC, overvoltage protection: 60 Vmax, reverse polarity protection: 80 Vmax
surge protection: min 64.4V/max 71.2V breakdown voltage
93.6V maximum reverse voltage @4.3A maximum reverse surge current - PoE-Out input voltage range
- 44 - 57 VDC
- Status LEDs
- 1 x Power LED, 10 x ETH status LEDs
- Grounding
- Grounding terminal on power connector
- Mounting
- Integrated DIN rail bracket
- Operating Temperature
- -40 °C to 75 °C
- Operating Humidity
- 5% to 95% non-condensing
- Ingress Protection Rating
- IP30
- Certifications
- CE, UKCA, RCM, CB, FCC, IC, WEEE
I/O Ports 2
- Ethernet: 5 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover
- Ethernet: 5 x RJ45 ports, 10/100 Mbps
