5 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover
Physical Interfaces: Ethernet
5 x RJ45 ports, 10/100 Mbps
Power & battery
Power: Input voltage range
12-40 VAC (50/60 Hz)
Power Consumption
Idle: 1 W / Max: 1.5 W
Power
1 x 3-pin industrial DC power socket
Physical & build
Weight
142 g
Dimensions (W x H x D)
113 x 28 x 50 mm
MAC address table size
2K entries
Casing material
Anodised aluminium housing and panels
Warranty & support
Jumbo frame support
9216 bytes
Other
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
Profinet
Profinet Class A conformance (available with optional order code)
Bandwidth (Non-blocking)
10 Gbps
Packer buffer
128 KB
Input voltage range
7 – 57 VDC, overvoltage protection: 60 Vmax, reverse polarity protection: 80 Vmax surge protection: min 64.4V/max 71.2V breakdown voltage 93.6V maximum reverse voltage @4.3A maximum reverse surge current
Status LEDs
1 x Power LED, 10 x ETH status LEDs
Grounding
Grounding terminal on power connector
Mounting options
Integrated DIN rail bracket
Operating temperature
-40 °C to 75 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP30
I/O Ports 2
Ethernet: 5 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover
