Weight0.50 lb
Specifications 30 normalized
Connectivity
- Networking
- 5 x RJ45 ports, 10/100/1000 Mbps
- Surge Immunity (AC Mains Power Port)
- EN 61000-4-5:2014 + A1:2017
Power & battery
- Power Consumption
- < 0.4 W/ < 1.8 W
- Power
- 1 x 4-pin power connector
Physical & build
- Weight
- 227 g
- Dimensions (W x H x D)
- 100 x 30 x 85 mm
- MAC address table size
- 2K entries
- Casing material
- Full aluminium housing
Warranty & support
- Jumbo frame support
- 9216 bytes
Other
- ETH
- 5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
- IEEE 802.3 series standards
- 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
- Profinet
- Profinet Class A conformance (available with optional order code)
- Bandwidth (Non-blocking)
- 10 Gbps
- Packer buffer
- 128 KB
- Input voltage range
- 9 – 30 VDC
- PoE (passive)
- Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
- Status LEDs
- 1 x Power LED, 10 x ETH status LEDs
- Other
- 1 x Grounding screw
- Mounting
- DIN rail, wall mount, flat surface (all require additional kit)
- Operating Temperature
- -40 °C to 75 °C
- Operating Humidity
- 5% to 95% non-condensing
- Ingress Protection Rating
- IP30
- Certifications
- CE, UKCA, EAC, UCRF, ANRT, CITC, Kenya, FCC, IC, NOM, RCM, BSMI, CB, MTCTE
- Standards
- EN 55032:2015 + A11:2020
EN 61000-3-3:2013 + A1:2019
EN IEC 61000-3-2:2019
EN 55035:2017 - ESD
- EN 61000-4-2:2009
- Radiated Immunity
- EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
- EFT
- EN 61000-4-4:2012
- CS
- EN 61000-4-6:2014
- DIP
- EN 61000-4-11:2004 + A1:2017
- Safety: Standards
- IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
I/O Ports 2
- ETH: 5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
- Ethernet: 5 x RJ45 ports, 10/100/1000 Mbps
